No. Name Included
in standard
delivery of
the security
lock
MUST!
Manda-
tory *
Available
as an
accesso-
ry or as
an option
Supplied by
customer/
not included
in standard
delivery
1
autoLock AV3 (Automatic locking system STV-AV3...) X X
2
Motor housing EAV3 X X
3
Keep rail STV-SL.../extension keep set STV-Grt.
SL.../single keeps STV-SB...
X X
4
Center keep STV-SB FRA ... AV... X X
4.2
Magnetic trigger X
4.3
Daytime latch TaFa X
5
Cable transition sash part STV-KÜ-T1 FT 2M/3,5M X X
5.1
Cable at the sash side 2 m or 3.5 m long, plug for
motor housing included
6
Frame part (suitable the sash part STV-KÜ...) X
6a
Figure 2-1: STV-KÜ-T1 RT KABEL 4M X
6.1
including cable 4 m for connection of external ac-
cess controls, eg. intercom, potential-free contact
6b
Figure 2-2: STV-KÜ-T1 RT KABEL 0,6M RNT
with plug connection to the frame power supply
12 V DC (optional)
X
7
Power supply X
7a
Figure 2-1: STV-HT NETZTEIL 12 V DC/2 A X
7b
Figure 2-2: STV-NETZTEIL RAHM. 12 V DC 1,5 A
(2A/2S) (optional)
X
7.1
including cable for connection of external access
controls, eg. intercom, potential-free contact
8
Access control system (shown: antenna of the
transponder set)
NOTICE! Only install the antenna of the trans-
ponder set in the external zone around the entry
door!
X
9
“Open” button X
10
Flush-type box X
11
Handle X
*
remaining components recommended for use, or should be used alternatively
