Part Description DIN right DIN left
STV-AV3-U2462 L79/50 A9 92/8 M2 RS/LS MC 5009375 5009374
STV-AV3-U2462 L79/50 A9 92/10 M2 RS/LS MC 5022949 5023000
STV-AV3-U2462 L79/55 A9 92/8 M2 RS/LS MC 5020687 5020688
STV-AV3-U2469 L79/35 A9 92/8 M2 RS/LS MC 5008030 5008029
STV-AV3-U2469 L79/35 A9 92/8 M2 RS/LS GR 5008028 5008024
STV-AV3-U2469 L79/40 A9 92/8 M2 RS/LS GR 5032409 5032410
STV-AV3-U2469 L79/45 A9 92/8 M2 RS/LS MC 5008076 5008075
STV-AV3-U2469 L79/45 A9 92/8 M2 RS/LS GR 5017259 5017260
STV-AV3-U2469 L79/45 A9 94/8 KABA M2 RS/LS MC 5009979 5009980
STV-AV3-U2469 L79/45 A9 92/10 M2 RS/LS MC 5023005 5023006
STV-AV3-U2469 L79/50 A9 92/8 M2 RS/LS MC 5008078 5008077
STV-AV3-U2469 L79/50 A9 94/8 KABA M2 RS/LS MC 5009981 5009982
STV-AV3-U2469 L79/50 A9 92/10 M2 RS/LS MC 5023001 5023002
STV-AV3-U2469 L79/55 A9 92/8 M2 RS/LS MC 5020133 5020134
STV-AV3-U2469 L79/65 A9 92/8 M2 RS/LS MC 5045178 5045179
STV-AV3-U2471 L79/35 A9 92/8 M2 RS/LS MC 5008071 5008070
STV-AV3-U2471 L79/35 A9 92/8 M2 RS/LS GR 5006204 5006203
STV-AV3-U2471 L79/35 A9 92/8 M2 RS/LS EST 5014877 5014878
STV-AV3-U2471 L79/40 A9 92/8 M2 RS/LS MC 5023206 5023207
STV-AV3-U2471 L79/45 A9 92/8 M2 RS/LS MC 5014884 5014885
STV-AV3-U2471 L79/45 A9 92/8 M2 RS/LS GR 5006207 5006206
STV-AV3-U2471 L79/55 A9 92/8 M2 RS/LS MC 5008073 5008072
STV-AV3-U2471 L79/65 A9 92/8 M2 RS/LS MC 5014883 5014882
STV-AV3-U2471 L79/65 A9 92/8 M2 RS/LS EST 5014886 5014887
STV-AV3-U247169 L79/55 A9 92/8 M2 RS/LS MC 5008180 5008119
STV-AV3-U247169 L79/35 A9 92/8 M2 RS/LS GR 5008118 5008117
STV-AV3-U2480 L79/45 A9 92/10 M2 RS/LS MC 5008193 5008192
STV-AV3-U2480 L79/50 A9 92/8 M2 RS/LS MC 5015506 5015505
STV-AV3-U2488 L79/35 A9 92/8 M2 RS/LS MC 5014946 5014947
STV-AV3-U2488 L79/35 A9 92/8 M2 RS/LS GR 5014918 5014930
