Print-no. 504 474 4
01/2017
Installation, Operating and Maintenance
Instructions blueMatic EAV
20
Aug. Winkhaus GmbH & Co. KG · Berkeser Str. 6 · D-98617 Meiningen www.winkhaus.de
Subject to technical changes
4.2 Magnetic trigger for center keep FRA ... AV ...
Contact-free magnetic release for autoLock AV3. Can be retrot-
ted in center keeps FRA ... AV ... with magnet hole.
STV-G1 MAGNETIC TRIGGER 13 MV AV3 5009111
STV-G1 MAGNETIC TRIGGER 13 UMV AV3 5009110
STV-G1 MAGNETIC TRIGGER 9 MV AV3 5014379
STV-G1 MAGNETIC TRIGGER 9 UMV AV3 5009109
4.3 Daytime latch TaFa
Fold-down daytime latch with mechanical adjustability by means
of the blue Winkhaus lever.
Variants
a) Daytime latch for standard doors
STV-DAYTIME LATCH 9/91 TAFA FA RS 5006561
STV-DAYTIME LATCH 9/91 TAFA FA LS 5006562
STV-DAYTIME LATCH 10/9 TAFA FA RS 5006563
STV-DAYTIME LATCH 10/9 TAFA FA LS 5006564
b) Daytime latch with “reinforced spring” for heavy-duty
doors (in case of increased wind loads or pressure)
STV-DAYTIME LATCH 9/91 TAFA FA STARK RS 5015109
STV-DAYTIME LATCH 9/91 TAFA FA STARK LS 5015108
STV-DAYTIME LATCH 10/9 TAFA FA STARK RS 5015111
STV-DAYTIME LATCH 10/9 TAFA FA STARK LS 5015110
c) Latch plate (accessory/spare part)
STV-LATCH PLATE A-9/91 TAFA FA MC (standard) 5011393
STV-LATCH PLATE A-10/9 TAFA FA MC
(less pressure)
5011392
