blueMatic EAV Installation, Operating and
Maintenance Instructions
Figure 3.6.2-3: Installation blueMatic EAV with Fingerprint ekey home micro
plus „Control unit, milled on the hinge side“ (sash side)
white   V DC
brown  V
green external opening signal
yellow
grey
pink (unscript)
yellowgrey  output signal swing door
opener (optional) only by
motor housing swing door
greenwhite  input for external po-
tential-free contact (eg
unlocking via intercom
open button)
Notice! max  m extendable
(min  mm

)
Description Part-no.
Sash part cable transition
T-KÜ-T FT EKEY MICRO
(PLUS) M

Frame part cable transiti-
on T-KÜ-T RT Kabel M
for external power supply
mounting on DIN rail

Motor housing EAV for
retrofitting mechanical
locking system AV
standard

to ekey WH-EAV
Set Arte micro plus with App
round face plate  mm
square face plate  mm
ekey


ekey Adapter micro plus WH EAV
WH KÜ Y-connection from cable
transition to control unit SE micro
plus (Arte) and motor housing
plugnplay
Fingerprint Arte ekey FS AR ED V
SV  x 
Control unit ekey home SE micro
plus  (is milled  mm)
ekey KAB AA  m x 
SHCP Connection between
ekey fingerprint Arte and control
unit SE micro plus 
}
signal swing door
opener
