Winkhaus blueMatic EAV - Page 57

Notice: The positioning of
frame power supply and
cable transition on the hinge
side is recommended, either
between lower / middle door
hinge or in each case approx.
10 cm above / below the
middle door hinge.
504474457
3
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMatic EAV Installation, Operating and
Maintenance Instructions
Figure 3.6.2-4: Installation blueMatic EAV with Fingerprint ekey home micro plus
„Control unit, milled on the hinge side“ and frame power supply (sash side)
Do
not connect
external
voltage!
yellowgrey  output signal swing door opener
(optional) only by motor housing
swing door
greenwhite  input for external potential-free
contact (eg unlocking via inter-
comopen button)
Notice! max  m extendable
(min  mm

)
white   V DC
brown  V
green external opening signal
yellow
grey
pink (unscript)
230 V AC
Description Part-no.
Sash part cable transition
T-KÜ-T FT EKEY MICRO
(PLUS) M

Frame part cable transition
T-KÜ-T RT KABEL M
RNT for frame power supply

Extension cable T-LB
VERLKABEL M RNT
ZU KÜ-T

Motor housing EAV for
retrofitting mechanical
locking system AV
standard

Frame power supply
T-NETZTEILRAHM  V
DC  A (AS)

to ekey WH-EAV
Set Arte micro plus with App
round face plate  mm
square face plate  mm
ekey


ekey Adapter micro plus WH EAV WH
KÜ Y-connection from cable transiti-
on to control unit SE micro plus (Arte)
and motor housing plugnplay
Fingerprint Arte ekey FS AR ED V
SV  x 
Control unit ekey home SE micro
plus  (is milled  mm)
ekey KAB AA  m x 
SHCP Connection between
ekey fingerprint Arte and control
unit SE micro plus 
}
signal swing door
opener
