Figure 3.6.2-8: Installation blueMatic EAV with Fingerprint IDENCOM BioKey
INSIDE and frame power supply (sash side)
Notice: The positioning of
frame power supply and
cable transition on the hinge
side is recommended, either
between lower / middle door
hinge or in each case approx.
10 cm above / below the
middle door hinge.
Do
not connect
external
voltage!
yellowgrey  output signal swing door opener
(optional) only by motor housing
swing door
greenwhite  input for external potential-free
contact (eg unlocking via
intercomopen button)
Notice! max  m extendable
(min  mm

)
white   V DC
brown  V
green external opening signal
yellow
grey
pink (unscript)
}
signal swing door
opener
230 V AC
Description Part-no.
Sash part cable transition
T-SET KÜ-T FT ZK-EAV
  Y  M including
Y-KABEL ZK FLÜGEL-EAV

Frame part cable transition
T-KÜ-T RT KABEL M
RNT for frame power
supply

Motor housing EAV for
retrofitting mechanical
locking system AV
standard

Frame power supply
T-NETZTEILRAHM  V
DC  A (AS)

Access control systems
ekey WH-EAV Set
Integra micro with App
ekey

Fingerprint IDENCOM
BioKey INSIDE Basic
without App
IDENCOM
 
Fingerprint IDENCOM
BioKey INSIDE with App
IDENCOM
 
