504474472
4
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMatic EAV Installation, Operating and
Maintenance Instructions
Action Acoustic Signal Result
) Press buttons A and
B (of a programmed
remote control) simul-
taneously*
n
short
Teach-in mode
started
) Press A button
(of the same remote
control)
nnnnnnnnnn
continuous signal (as
long as teach-in mode
is active)
Teach-in mode
active
) Press all buttons to
be taught in succession
as long as the teach-in
mode is active
nnnn nnnn
continuous signal is
briefly interrupted
pressed button(s)
isare authorised
* If no remote control has been taught (e.g. after delete-all function), it would
apply to all remote control. The teach-in mode can be started with any
remote control.
Deleting wireless remote controls directly via the remote control
Partial deletion
Action Acoustic Signal Result
) Press buttons A and
B (of a programmed
remote control) simul-
taneously*
n
short
Teach-in mode
started
) Press A button
(of the same remote
control)
nnnnnnnnnn
continuous signal (as
long as delete mode is
active)
Teach-in mode
active
) Press all buttons to
be deleted in successi-
on as long as the delete
mode is active
nnnn nnnn
continuous signal is
briefly interrupted
pressed button(s)
isare deleted
