blueMatic EAV Installation, Operating and
Maintenance Instructions
Number of code combinations:
2 to the power of 64 ("Rolling Code")
Modulation: AM/ASK
Rated output E.R.P.: 50 - 100 µW
Range in an unobstructed area:
max. 30 m
Dimensions: 61 x 36 x 16 mm
Wireless receiver (separate)
Receiver type: Superheterodyne
Modulation: AM/ASK
Frequency: 433,92 MHz
Frequency of the local oscillator:
6,6128 MHz
Intermediate frequency: 10,7 MHz
Sensitivity (to receive signals): -115 dB
Input impedance: 50 Ohm
Maximum memory capacity: 85 codes for remote control
Power supply: 12/24 V AC/DC
Closed-circuit current: 15 mA
On-load current: 33/48 mA
Number of relays: (1 NO-NC)
Power: 24 W
Dimensions: 80 x 80 x 50 mm
7.6 Cable transition T-KÜ-T1 FT
General Specifications
Dimensions: Overall length approx. 260 mm
Cross section of wires: 6 x 0.25 mm
2
Max. voltage: 48 V DC
Max. switching current: 2 A per connection line/wire
Screw fixing: 3 piece 3 x 20 mm, 1 piece 2.9 x 32 mm
(included in set sash part)
Cable transition T-KÜ-T1 FT sash part
Sash part: • T-KÜ-T1 FT 2 M with 2 m cable + plug for
motor housing
• T-KÜ-T1 FT 3,5 M with 3.5 m cable + plug for
motor housing
• T-KÜ-T1 FT 4,5 M with 4.5 m cable + plug for
motor housing
