Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMatic EAV Installation, Operating and
Maintenance Instructions
T-SET KÜ-T1 FT ZK-SO ENTRA+ EAV 1,5 + 3M
Plug'n'play solution for fingerprint
SOMMER ENTRAsys FD
(sash side)
Sash part:
Cable transition
KÜ-T1 SOMMER-ENTRA+ FT
Cable at the sash side 1.5 m (6 x 0.25 mm),
Cable ends with 5-pole plug for radio receiver
ENTRAsys+ RX
Accessories/included in the set:
• Connecting cable ANSCHLUSSKAB. EAV
SOMMER ENTRAsys+ 3 m (3 x 0.25 mm)
- 1st Cable end with plug for motor housing EAV
- 2nd Cable end with plug for radio receiver
ENTRAsys+ RX
Max. voltage: 48 V DC
Max. switching current: 2 A per connection line/wire
Cable transition frame part (order separately)
Frame part: • T-KÜ-T1 RT KABEL 4 M with 4 m cable and
cable end sleeves
• T-KÜ-T1 RT KABEL 0,6 M RNT with 0.6 m
cable and plug for frame power supply
T-KÜ-T1 FT EKEY MICRO (PLUS) 1,5 M
Plug'n'play solution for fingerprint ekey micro or ekey micro plus (sash side)
Sash part: KÜ-T1-EV-G FLÜGELTEIL 1,5 M
cable at the sash side 1.5 m (6 x 0.25 mm),
cable ends with 5-pole plug connection with
ekey micro or ekey micro plus (plug in)
Max. voltage: 48 V DC
Max. switching current: 2 A per connection line/wire
