Winkhaus blueMatic EAV - Electromechanical Locks according to EN 14846; VdS Acceptance (based on VdS 2344, 2201); Certificat DIN 18251-3

Notice: Suitable for fire and smoke protection doors
(Special version = with steel latch).
504474488
9
EN
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.de ∙ Subject to technical changes
blueMatic EAV Installation, Operating and
Maintenance Instructions
9.1 Electromechanical locks according to EN 14846
Artikel No. Backset Centre
distance
Faceplate Classification
T-EAV  -  mm 92 mm PZ
94 mm RZ
Flat ≥ 16 mm
U ≥ 22 x 5 mm
 S  C  G   
T-EAV  -  mm 92 mm PZ
94 mm RZ
Flat ≥ 16 mm
U ≥ 22 x 5 mm
 S  C  G   
T-AVB  -  mm 92 mm PZ
94 mm RZ
Flat ≥ 16 mm
U ≥ 22 x 5 mm
 S  C  G   
9 Classification/Declaration of performance
Acceptance class A for autoLock AV2,
Acceptance-No.: M105301
Acceptance class B for autoLock AV3,
Acceptance-No.: M113345
9.2 VdS Acceptance (based on VdS 2344, 2201)
9.3 Certificat DIN 18251-3
The company Aug. Winkhaus GmbH & Co. KG is certified, that it has fulfilled the
requirements of DIN 18251 "Safety-relevant characteristics according to Table 3,
Class 4 according to DIN 18251-3: 2002-11".
Acceptance/Basis of the Approval
VdS 2344:2014-07
VdS 2201:2004-02
DIN 18 251-3:2002-11
