M101H Series User Guide 53
Change Touchscreen Modes
The tablet’s advanced capacitive touchscreen has 3 built-in operating modes, for users to choose
under different usage scenarios:
Mode
Usage Scenario
Hand/Rain Mode
The Hand/Rain mode is the default operating mode of the touchscreen. Under
this mode, the touchscreen is set to have the ability to reject false touch inputs
while liquid is present on the touchscreen. Once the liquid is removed from the
touchscreen, touch inputs from bare fingertips will continue to operate.
Support the following input solutions:
 Active stylus w/ palm rejection
 Rubber Tip passive stylus
 Finger
Stylus Mode
Under the Stylus mode, the touchscreen is set to have the ability to pick up touch
inputs from the fine-tip passive capacitive stylus that is shipped with the tablet.
Touch inputs from bare fingertips will also continue to operate.
Support the following input solutions:
 Fine-tip passive stylus w/ palm rejection
 Active stylus w/ palm rejection
 Rubber Tip passive stylus
 Finger
Glove Mode
Under the Glove mode, the touchscreen is set to have the ability to pick up touch
inputs while the user is operating the touchscreen with gloves on. Touch inputs
from bare fingertips will also continue to operate.
Support the following input solutions:
 Glove
 Rubber Tip passive stylus
 Finger
There are 2 ways to switch between the different touchscreen operating modes:
(1) Via the built-in HotTab utility
(2) Via the programmable function buttons
Switch via Built-in HotTab Utility
To switch between the different touchscreen modes via the HotTab utility, perform the following
procedure:
1. Open HotTab utility by pressing (Menu) Button located on the front panel, OR
launching HotTab Utility application.
2. Choose “Device ON/OFF” and then click on “Touch Set” icon

