Regular cleaning
32 ES 7100 PLUS 10.2011
Cleaning the cup carrier
• Remove the cup carrier: Take hold of the
cup carrier with your right hand and with
your left hand remove the corresponding
retaining pin, situated on the rear side of
the cup station. (fig. 17).
• Disassemble cup carrier (fig. 18). Clean
the drip grid (a) and tray (b) in hot water
with cleaning agent and dry parts.
The complete cup carrier is dish-
washer-proof.
17 18
