Deep cleaning
10.2011 ES 7100 PLUS 45
Mounting cleaned parts
• Push the outlet tubes downwards to open
the outlet spouts of the canisters (fig. 45).
• Fill coffee bean canister and re-insert in
machine.
• Pull out shutter (bean stop) to open
position, after canister is repositioned.
• Reinstall espresso brewer taking care that
the crank arm of the coffee motor
engages correctly into the drive shaft of
the brewer (fig. 46).
When reinstalling brewer, check
that the crank arm of the coffee
motor is correctly engaged in its
seat.
• Re-insert hoses at top of the brewer
(fig. 47).
Check that the hoses at top of the
brewer are properly seated by pull-
ing upwards.
If properly seated, the hoses will be
retained by the locking rings.
45 46 47
