118
9.2 Technical data
Rated power * 9,3 kW 13,8 kW
Hourly output **
with starting supply
430 cups
490 cups
500 cups
560 cups
2 Storage urns
4,0 litres each
Hot water output, total
72 l/h 108 l/h
2 Ground coffee hoppers
2,2 kg each
Electricity supply*
3/N/PE 50 Hz/400 V
External dimensions:
Width, machine for two types of coffee
Height with ground coffee hopper
Depth
700 mm
810 mm
590 mm
Empty weight:
Machine for two types of coffee approx. 98 kg
Continuous sound pressure level (Lpa) ***
< 70 dB (A)
Heat emission
Stand-by
Full load *
200 W
9150 W
200 W
13650 W
Technical data subject to change without notice.
* Values quoted apply to basic version. For special versions, see rating plate.
** The hourly outputs indicated are GUIDELINES and depend, among other things, on the quantity of ground
coffee, coffee beverage, brewing temperature, brewing aperture size, brewing pressure, water hardness and
general condition of the machine (e.g. limescale, connections, power, water, sequence, wear, etc.)
*** The A-weighted mean sound pressure level Lpa (slow) and Lpa (impulse) at the operator’s workplace is
below 70 dB(A) in every operating mode.
