INDUCTION RANGE ERROR CODES
Error
Code
Shown Phrase PRI Component Error Description Service Instruction
5522 eSecondaryStalledCoolingFan 2 Left oven
1 Check the cooling fan operation.
2 Check the high-voltage cooling
fan motor circuitry.
3 Check the low voltage to the
cooling fan speed sensor.
4 Replace the relay board.
5321 eUIMAmbientExceedsTemperat
ure
2 UIM The UIM ambient
temperature sensor is
over 185°F (85°C).
1 Reset the power supply.
2 Reseat the UIM wire
connections.
3 Replace the UIM.
6320 eUIMInvalidConfigurationData 2 UIM The configuration data on
the UIM is corrupt or has
invalid values.
1 Reset the power supply.
2 Reseat the UIM wire
connections.
3 Replace the UIM.
6A10 eUIMMemoryFault 1 UIM The RAM on the UIM has
failed the memory test.
1 Reset the power supply.
2 Reseat the UIM wire
connections.
3 Replace the UIM.
6C30 eUSBCommunicationFault 2 UIM The UIM detects an error
on the USB network.
1 Replace the UIM.
8110 eUIMDisplayFault 2 UIM The UIM display has a
fault.
1 Reset the power supply.
2 Reseat the UIM wire
connections.
3 Replace the UIM.
9010 ePODTouchScreenFault 2 ECH The touch screen is not
responding to inputs.
1 Reset the power supply.
2 Reseat the ECH wire
connections.
3 Replace the ECH.
2F21 Generic Hardware error - High
Voltage
2 Right relay board Hardware fault on the
high-voltage control of
the relay board.
1 Replace the relay board.
2F22 Generic Hardware error - High
Voltage
2 Left relay board Hardware fault on the
high-voltage control of
the relay board.
1 Replace the relay board.
3F21 Keep Alive timeout 2 Right relay board The relay board did not
receive any "Set oven
output status" messages
within the given time
period.
1 Replace the relay board.
3F22 Keep Alive timeout 2 Left relay board The relay board did not
receive any "Set oven
output status" messages
within the given time
period.
1 Replace the relay board.
0C21 Relay board over temperature
shutdown
2 Right relay board The NTC thermal cutoff
on the relay board is
active.
1 Replace the relay board.
