Wolf 30 - Technical Data; 36 COOKTOP POWER LEVELS

36" COOKTOP POWER LEVELS
Level LEDs
Shown
% of Total
Rating
2100 W - Left
Rear
2100 W - Left
Front
2600 W -
Center
2100 W -
Right Rear
2100 W -
Right Front
Operation
Time Limit
0 0 0.00% 0.0 0.0 0.0 0.0 0.0
1 MLT/SIM 2.00% 42.0 42.0 52.0 42.0 42.0 8 Hours
2 2 5.50% 115.5 115.5 143.0 115.5 115.5 8 Hours
3 3 11.00% 231.0 231.0 286.0 231.0 231.0 6 Hours
4 4 16.50% 346.5 346.5 429.0 346.5 346.5 6 Hours
5 5 22.00% 462.0 462.0 572.0 462.0 462.0 6 Hours
6 6 26.50% 556.5 556.5 689.0 556.5 556.5 6 Hours
7 7 35.50% 745.5 745.5 936.0 745.5 745.5 6 Hours
8 8 50.00% 1050.0 1050.0 1300.0 1050.0 1050.0 2 Hours
9 9 75.00% 1575.0 1575.0 1950.0 1575.0 1575.0 2 Hours
10 HI 100.00% 2100.0 2100.0 2600.0 2100.0 2100.0 2 Hours
Boost Boost N/A 3700.0 3700.0 3700.0 3700.0 3700.0 15 Minutes
36" Cooktop Boost Performance:
• The two left coils form a group.
• The center coil is its own group.
• The two right coils form a group.
• Each group is visually limited to 4200 W.
• If either of the left coils are on Boost, the other left coil is limited to Power Level 5.
• If either of the right coils are on Boost, the other right coil is limited to Power Level 5.
• If the requested power usage in either group exceeds 3700 W, both coils are proportionally derated to make sure the power usage stays
under 3700 W.
• The display does not show the derating of the coils.
Coil Locations
30" and 36" Induction Range
Technical Data
Induction Range Technical Data
