Rev AB Terminals 9-11
Wolke m600 touch Operator Manual
Terminals
Power Supply
Table 9-4 lists the power supply performance values.
Type of Connection
Wolke m600 touch is equipped with a directly mounted plug housing. A
connecting cable, approximately 1.8 m length, with matching connector
will also be included while delivering the Wolke m600 touch printer.
Shaft Encoder Socket
The shaft encoder connected to this socket enables the Wolke m600 touch
printer to determine the speed of the product being printed. Refer to
“Commissioning” on page 5-1.
The standard shaft encoder supplied by Wolke delivers 2,500 pulses per
revolution. Four different drive discs are available for the shaft encoder. If
the measurement wheel is positioned directly on the product conveyor
belt, the resultant values are as shown in Table 9-5. The number of pulses
per meter has to be entered in the Adjustments/Installation menu.
Table 9-5 lists the values for pulses/meter depending on measuring wheel
diameter.
Value Range
Power Supply
Requirements
90 - 264 V,
47 - 63 Hz,
single-phase type ‘TN’ or ‘TT’ 320 VA (max),
2.75A @ 115 V AC, 1.4A @ 230 V AC, 60A max
surge @ 230 V, 30A max surge @ 115 V
Table 9-4: Power Supply Performance
Drive disk model Diameter Standard values
Pulses/m
Aluminium measuring wheel
(solid material)
67,33 mm 11.819
Rubber measuring wheel
(studded)
63,66 mm 12.500
Solid aluminium with cross
spokes
63,66 mm 12.500
Table 9-5: Values for Pulses/Meters
