Using the Home Page
The Home page allows the user to access the following pages:
• Printer Status Bar: Provides information about the status of the printer
like Running if the printer is online, Offline if the printer is
disconnected, Shutdown if the printer is switched off.
• Tools Button: Permits the user to access the Tools page.
• Current Job Details Page: Displays the information about the current
job.
• Consumables Information: Provides information about the status of
the consumables like printing ink.
• Print Position: Permits the user to set the product delay parameters.
Product delay is the time between the start of the product (trigger
point) and the print start position.
• Performance Information: Provides information about the number of
jobs produced in a batch, total number of individual jobs printed and
the speed at which the job is printed, ignored printhead print signal
details and so on.
Figure 4-1: CLARiTY
®
Home Page
2
3
7
8
1. Printer Status Bar
2. Tools Button
3. Current Job Details Bar
4. Consumables Information
5. Print Position
6. Performance Information
7. System Control Buttons
8. Home Button
9. Job Select Button
1
4
6
5
9
