Fixed speed
Fixed Speed mode should only be used when the speed of the conveyor is
constant and critical information is not to be printed.
Note: If fixed speed mode is selected and the linear speed of the conveyor should
change, the length of the image printed will either increase or reduce accordingly.
Installation of the Mounting System (Optional)
The mounting system for single-head mounting allows fast and simple
printhead mounting.
The adjusting unit for multi-head mounting (all printhead versions) is as
shown in Figure 3-38. This enables printheads to be finely adjusted for
perfect print images.
Figure 3-37: Single-head Mounting of a Blue Printhead
Figure 3-38: Adjusting Unit
