Printhead Arrangement
Figure 3-25: Wolke m600 touch with Four Printheads
1
1. All on one side
2. Two each on the left and right
3. Three on the left and one on the right
4. At the top, left and right
5. At the top
6. Side and at the top
2 3
456
