Rev AB Installation of the Parallelogram (Optional) 3-27
Wolke m600 touch Operator Manual
The stainless steel mounting system for red and green printheads is shown
in Figure 3-42. This mounting system is especially well suited for the
pharmaceutical, medical and food industries. The mounting adapter for a
red or green printhead assembly is available in a length of 200 mm.
The stainless steel mounting adapter for blue printhead is shown in
Figure 3-43. The mounting adapter for a blue printhead assembly is
available in a length of 200 mm.
The mounting adapter for a gold printhead assembly is available in a
length of 200 mm.
Installation of the Parallelogram (Optional)
Many products and packaging materials (example, wrapping) are slightly
uneven/cambered or are transported on the conveyor belt in a range of
different positions.
In these cases the parallelogram with measuring wheel or deflector
described under accessories (see “Specifications” on page 9-1) should be
Figure 3-42: Stainless Steel Mounting System
Figure 3-43: Stainless Steel Mounting Adapter - Blue Printhead
Figure 3-44: Stainless Steel Mounting Adapter - Gold Printhead
