wolke M600 - Head Plates; Ink Cartridge; Product Sensor

3-4 Integral Parts and Accessories Rev AB
Wolke m600 touch Operator Manual
Head Plates
The head plates are available in different versions, one, two, three or four
heads, to install on the underside of the printheads.
Ink Cartridge
Ink cartridges are available with a range of ink types for the different
substrates.
Product Sensor
The product sensor and associated components detect the print material
and transfers the print signal.
Figure 3-4: Head plates
Figure 3-5: Ink Cartridge
Figure 3-6: Sensor
