Wood-mizer LT70 User Manual

REPLACEMENT PARTS
Hydraulic Control Box, 7-Section Remote Control
3
3-11 doc070822 REPLACEMENT PARTS
6 FITTING, 1/2NPT-3/8 BARB ELBOW P12707 2
7 BOLT, 1/4-20 X 1/2" HEX HEAD F05005-15 2
8 WASHER, Z 6.1 SPLIT LOCK ZINC F81053-3 2
9 FITTING, 6SAE MALE-1/4NPT FEMALE 014686 2
10 FITTING, C3759X4 MALE TEE 015486 1
11 FITTING, 3/8JIC-1/4NPT 90L 015491 2
12 PLUG, 1/4-18 NPT BLANK 096221 1
13 FITTING, 3/8NPT-3/8 ELBOW P12708 1
14 FITTING, 3/8 BARB TEE 015485 1
15 WASHER, 8.4 FLAT ZINC F81054-1 36
16 NUT, M8-8-B HEX NYLON ZINC LOCK F81032-2 14
17 PLATE, REMOTE HYDRAULIC CONTROL BOX REAR 500516-1 1
18 PLATE, REMOTE HYDARULIC CONTROL BOX FRONT 500122-1 1
19 GUARD, RUBBER HYDRAULIC VALVE 10-SECTION 091739 1
20 BOLT, #10-24X1/2 SELF-TAPPING F05015-7 12
21 PANEL, HYDRAULIC BOX REAR 500124-1 1
22 GROMMET, 4 3/8 X 10 OVAL RUBBER 085759 1
23 WASHER, 10.5 FLAT ZINC F81055-1 10
24 BOLT, M10X25-8.8-FE/ZN5 F81003-11 2
25 VALVE, 7-SECTION HYDRAULIC 510560 1
26 GUARD, LT70 AC REMOTE CONTROL BOX (PC) 090219 1
27 FITTING, 1/4NPT-3/8 BARB 014685 1
28 FITTING, 3/8" O-RING X 3/8" JIC 014687 5
29 FITTING, #6SAE 45 DEG ELBOW 015489 1
30 FITTING, #4 SAE - #6 SAE 45¶ ELBOW 015488 7
31 FITTING, 1/4JIC-3/8 O-RING P26284 8
32 BRACKET, CONTROL BOX GUARD 500766-1 1
33 BRACKET, CONTROL BOX GUARD - LEFT 500767-1 1
34 BOLT, M8X25-8.8-B HEX HEAD FULL THREAD Z F81002-5 14
35 BOLT, M8X16 -8.8-B HEX HEAD FULL THREAD F81002-20 8
36 BOLT, M8X20-8.8-B HEX HEAD FULL THREAD Z F81002-4 4
37 WASHER, 6.4 FLAT ZINC F81053-1 6
38 CAP, 44.5 MM NO. 466923 HOLE 500768 2
39 BOLT, M10X35-8.8 HEX HEAD FULL THREAD ZI F81003-17 4
40 NUT, M10-8-B HEX NYLON ZINC LOCK F81033-1 4
41 COVER, HYDRAULIC HOSE - SPECIAL 502500-1 1
42 BUSH, MOSS 44.5MM 465901 SNAP-FIT R80670-3 2
43 FITTING, 3/8" JIC - 1/4" NPT STRAIGHT 015560 1
44 FITTING, PN10AFL 13-90 ELBOW 094485 1
45 FITTING, VMNW10HS22 094486 1
46 CLAMP, 11/16 WORM 061807 8
47 BOLT, M6X16 8.8 HEX HEAD FULL THREAD ZIN F81001-15 8
48 FITTING, M22X1.5 / 1/4 -18 NPT ZINC-PL. 093139-1 2
49 MICROSWITCH, HYDRAULIC VALVE 014765 1
50 CONTACT ASSEMBLY, LT40/70 AC NEGATIVE 086624 1
REF. DESCRIPTION (* indicates parts available in assemblies only) PART # QTY
