Remote Operation
Remote Sawmill Operation
Remote Operation ROdoc070822 1-6
1
1.4 Remote Sawmill Operation
See Figure 1-5. All sawmill controls operate exactly as described in your sawmill
operator’s manual except the clutch/brake. Instead of pulling a handle to engage the
blade, push the toggle switch on the control panel up. Hold the switch up until the clutch
motor stops completely. The remote clutch mechanism will disengage the brake, rev the
motor to full throttle, and start the blade spinning.
DANGER! Keep all persons out of the path of moving
equipment and logs when operating sawmill or loading and
turning logs. Failure to do so will result in serious injury.
To stop the blade and engage the blade brake, push the toggle switch down. This will also
return the engine to idle.
NOTE: Be sure the toggle switch stays in the up or down position. The boot on the switch
may spring the switch back to neutral. You may need to hold the switch in position until
the remote clutch motor completes its cycle.
IMPORTANT! If you sawmill is equipped with board return tables, minimum board lenght
is 2 meter.
FIG. 1-5
