REPLACEMENT PARTS
Remote Control Box (14-Section) 2x5.5kW
REPLACEMENT PARTS doc070822 3-18
3
3.9 Remote Control Box (14-Section) 2x5.5kW
REF DESCRIPTION (u indicates parts available in assemblies only) PART # QTY
- REMOTE CONTROL BOX - COMPLETE -14-SECTION 2x5.5kW 550011 1
1 BASE, REMOTE CONTROL BOX WLDMT/PTD 539329-1 1
2 PLATE, REMOTE CONTROL BOX MOUNT 539333-1 1
3 HOUSING, CONTROL VALVE 550010-1 1
4 GROMMET, RUBBER 087065 1
5 VALVE, 7-SECTION AC HYDRAULIC 510560 2
6 COVER, HYDRAULIC VALVE HOUSING REAR 500515 1
7 GROMMET, RUBBER 4 3/8 X 10 OVAL 085759 2
8 MANIFOLD, W/FILTER P22683 1
9 FITTING, 1/2NPT-3/8 BARB ELBOW P12707 2
10 BOLT, 1/4-20X1/2 HH F05005-15 2
11 CLAMP, 11/16 WORM 061807 5
12 WASHER, Z 6.1 SPLIT LOCK ZINC F81053-3 2
13 FITTING, #4SAE-#6SAE 45 DEG ELBOW 015488 8
14 FITTING, #6SAE 45 DEG ELBOW 015489 1
15 FITTING, 6SAE MALE-1/4NPT FEMALE 014686 3
16 FITTING, 1/4NPT-3/8 BARB 014685 1
17 FITTING, 3/8 O-RING-3/8JIC 014687 12
To Next Page
