REPLACEMENT PARTS
Remote Control Box (16-Section)
3
3-17 doc070822 REPLACEMENT PARTS
16 FITTING, 6SAE MALE-1/4NPT FEMALE 014686 3
17 FITTING, 1/4NPT-3/8 BARB 014685 1
18 FITTING, 3/8O-RING-3/8JIC 014687 12
19 FITTING, 1/4JIC-3/8 O-RING P26284 4
20 HYDRAULIC PUMP W/MOTOR AC.4KW 14.5L/MIN 500958 1
21 FITTING, 1/4NPT MALE RUN TEE P09141 1
22 FITTING, 3/8JIC-1/4NPT 90L 015491 1
23 PLUG, 1/4Î NPT BLANK 096221 1
24 FITTING, 3/8NPT-3/8 BARB ELBOW P12708 1
25 FITTING, 3/8 BARB TEE 015485 1
26 BOLT, #10-24X1/2 SELF TAP F05015-7 20
27 GUARD, RUBBER DOUBLE VALVE 015079 1
28 SHELF, ELECTRIC BOX - COMPLETE 539352-1 1
29 WASHER, 8.4 FLAT ZINC F81054-1 36
30 NUT, M8-8-B HEX NYLON ZINC LOCK F81032-2 14
31 BOLT, M8X25-8.8-B HEX HEAD FULL THREAD Z F81002-5 10
32 PLATE, REMOTE CONTROL BOX REAR 500516-1 1
33 BOLT, M8X20MM,HH,GR 8.8,FULL THRD,ZINC F81002-1 4
34 GUARD, LT70 CONTROL BOX PC 090219 1
35 BRACKET, CONTROL BOX GUARD 500766-1 1
36 BRACKET, CONTROL BOX GUARD - LEFT 500767-1 1
37 WASHER, 10.5 FLAT ZINC F81055-1 21
38 NUT, M10-8-B HEX NYLON ZINC LOCK F81033-1 8
39 BOLT,M10X35-8.8 HEX HEAD FULL THREAD ZIN F81003-17 4
40 BOLT, M10X25-8.8-FE/ZN5 F81003-11 10
41 BOLT M8X16 -8.8-B-FE/ZN5 PN-85/M-82105 F81002-20 12
42 WASHER, 6.4 FLAT ZINC F81053-1 6
43 GUARD, CABLE 501102-1 1
44 GUARD, RUBBER HYDRAULIC VALVE 10-SECTION 091739 1
45 VALVE, HDS11/10- 8-SECTION HYDRAULIC 091344 1
46 PLATE, FRONT 500122-1 1
47 PLUG KIT (500508) 505060 1
48 CAP, 44.5 MM NO. 466923 HOLE 500768 1
49 BUSH, MOSS 44.5MM 465901 SNAP-FIT R80670-3 1
50 SWITCH, 2A 125V R-LEVER NO/NC/COM 014765 2
51 CONTACT ASSEMBLY, HYDRAULIC POWER SUPPLY 086624 1
52 CONTACT, ASSEMBLY HOT AC 086625 1
53 SLEEVE, LT40/70 0.6 THICK 3.5 LONG PROTE 510287 1
54 FITTING, 1/4NPT BRANCH TEE 015486 1
55 PLATFORM SIDE COMPLETE See Section 3.38
545626 2
