Wood-mizer LT70 User Manual

REPLACEMENT PARTS
Remote Control Box, 22-Section
3
3-23 doc070822 REPLACEMENT PARTS
14 FITTING, #4SAE-#6SAE 45 DEG ELBOW 015488 10
15 FITTING, #6SAE 45 DEG ELBOW 015489 1
16 FITTING, 6SAE MALE-1/4NPT FEMALE 014686 3
17 FITTING, 1/4NPT-3/8 BARB 014685 1
18 FITTING, 3/8 O-RING-3/8JIC 014687 12
19 FITTING, 1/4JIC-3/8 O-RING P26284 4
20 PUMP, AC.5,5KW 18.5L/MIN HYDRAULIC W/MOT 517840 2
21 FITTING, 1/4NPTX1/4JIC MALE RUN TEE P09141 1
22 FITTING, 3/8JIC-1/4NPT 90L 015491 1
23 PLUG, 1/4-18 NPT BLANK 096221 1
24 FITTING, 3/8NPT-3/8 BARB ELBOW P12708 1
25 FITTING 3/8 TEE BARB 015485 1
26 BOLT, #10-24X1/2 SELF-TAPPING F05015-7 20
27 SEAL, RUBBER VALVE HANDLE 015079 2
28 BRACKET, HYDRAULIC CONTROL BOX BASE - CO 539352-1 1
29 WASHER, 8.4 FLAT ZINC F81054-1 36
30 NUT, M8-8-B HEX NYLON ZINC LOCK F81032-2 14
31 BOLT, M8X25-8.8-B HEX HEAD FULL THREAD Z F81002-5 10
32 PLATE, REMOTE CONTROL BOX REAR (2 HYD. P 539331-1 1
33 BOLT, M8X20MM, HEX HEAD,GR 5.8 ZINC F81002-4 4
34 GUARD, LT70 AC REMOTE CONTROL BOX (PC) 090219 1
35 BRACKET, CONTROL BOX GUARD 500766-1 1
36 BRACKET, CONTROL BOX GUARD - LEFT 500767-1 1
37 WASHER, 10.5 FLAT ZINC F81055-1 22
38 NUT, M10-8-B HEX NYLON ZINC LOCK F81033-1 8
39 BOLT, M10X35-8.8 HEX HEAD FULL THREAD ZI F81003-17 4
40 BOLT, M10X25-8.8 ZINC F81003-11 10
41 BOLT M8X16 -8.8-B-FE/ZN5 PN-85/M-82105 F81002-20 12
42 WASHER, 6.4 FLAT ZINC F81053-1 6
43 GUARD, CABLE 501102-1 1
44 GUARD, RUBBER HYDRAULIC VALVE 10-SECTION 091739 1
45 VALVE, HDS11/10- 8-SECTION HYDRAULIC 091344 1
46 PLATE, FRONT 500122-1 1
47 PLUG KIT FOR 500508 505060 1
48 CAP, 44.5 MM NO. 466923 HOLE 500768 1
49 BUSH, MOSS 44.5MM 465901 SNAP-FIT R80670-3 1
50 SWITCH, 2A 125V R-LEVER NO/NC/COM 014765 2
51 CONTACT ASSEMBLY, AC NEGATIVE 086624 1
52 CONTACT ASSEMBLY, AC POSITIVE 086625 1
53 SLEEVE, LT40/70 0.6 THICK 3.5 LONG PROTE 510287 1
54 FITTING, 1/4NPT BRANCH TEE 015486 1
- PLATFORM SIDE COMPLETE 545626 2
55 PLATFORM SIDE WLDMT 545625-1 1
56 FLAT BAR MOUNTING BASE PLATFORM 545627-1 4
57 WASHER, 10.5 FLAT ZINC F81055-1 20
REF DESCRIPTION (u indicates parts available in assemblies only) PART # QTY
