Woodward GCP-30 Series Installation

Manual 37364A GCP-30 Packages - Genset Control
Operation Mode Selection Via DI (XPD, XPQ)
This functionality enables external selection of the operation mode using terminals 127 and 128. The discrete in-
puts can be connected using positive or negative logic as described above.
Terminal Associated
common
Description
(according to DIN 40 719 Part 3, 5.8.3)
A
max
127
124
Control input [terminal 127]
- Operation mode STOP
2.5 mm²
128
Control input [terminal 128]
- Operation mode AUTOMATIC
2.5 mm²
Table 5-12: Discrete inputs - operation mode selection
NOTE
The selection of the operation mode via discrete inputs 127/128 is only possible if the discrete input on
terminal 63 (Operation mode selector blocked) is energized. More detailed information may be found in
the configuration manual (37365) under 'Block operation mode selector switch via terminal 63'.
Page 32/46 © Woodward
