Manual 37364A GCP-30 Packages - Genset Control
Chapter 1.
General Information
Type English German
GCP-31/32 Series
GCP-31/32 Packages - Installation this manual Ö 37364 GR37364
GCP-31/32 Packages - Configuration 37365 GR37365
GCP-31/32 - Function/Operation 37238 GR37238
GCP-31/32 - Application 37240 GR37240
GCP-31/RPQ - Installation 37366 GR37366
GCP-31/RPQ - Configuration 37367 GR37367
Option SB - Caterpillar CCM coupling 37200 GR37200
Option SC09/SC10 - CAN bus coupling 37382 GR37382
Additional Manuals
IKD 1 - Manual 37135 GR37135
Discrete expansion board with 8 discrete inputs and 8 relay outputs that can be coupled via the CAN bus to the control unit. As-
sessment of the discrete inputs as well as control of the relay outputs is done via the control unit.
LeoPC1 - Manual 37146 GR37146
PC program for visualization, configuration, remote control, data logging, language upload, alarm and user management and man-
agement of the event recorder. This manual describes the use of the program.
LeoPC1 - Manual 37164 GR37164
PC program for visualization, configuration, remote control, data logging, language upload, alarm and user management and man-
agement of the event recorder. This manual describes the programming of the program.
GW 4 - Manual 37133 GR37133
Gateway for transferring the CAN bus to any other interface or bus.
ST 3 - Manual 37112 GR37112
Control to govern the air fuel ratio of a gas engine. The ratio will be directly measured though a Lambda probe and controlled to a
configured value.
Table 1-1: Manual - Overview
Intended Use: This control is intended to be operated according to the guidelines described in this manual. The
prerequisite for a proper and safe operation of the product is correct transportation, storage, and installation as
well as careful operation and maintenance.
NOTE
This manual has been developed for a control fitted with all available options. Inputs/outputs, func-
tions, configuration screens and other details described, which do not exist on your control may be ig-
nored.
The present manual has been prepared to enable the installation and commissioning of the control.
Due to the large variety of parameter settings, it is not possible to cover every combination. The ma-
nual is therefore only a guide. In case of incorrect entries or a total loss of functions, the default set-
tings can be taken from the list of parameters located in the appendix of the Configuration manual.
© Woodward Page 7/46
