Table 4-5 (continued). Boolean Read Addresses (Code 02)
ADDRESS DESCRIPTION
1:1071 Analog Input 9 LoLo
1:1072 Analog Input 10 LoLo
1:1073 Analog Input 1 Range Error
1:1074 Analog Input 2 Range Error
1:1075 Analog Input 3 Range Error
1:1076 Analog Input 4 Range Error
1:1077 Analog Input 5 Range Error
1:1078 Analog Input 6 Range Error
1:1079 Analog Input 7 Range Error
1:1080 Analog Input 8 Range Error
1:1081 Analog Input 9 Range Error
1:1082 Analog Input 10 Range Error
1:1083 Analog Comparator 1
1:1084 Analog Comparator 2
1:1085 Analog Comparator 3
1:1086 Analog Comparator 4
1:1087 Analog Comparator 5
1:1088 Analog Comparator 6
1:1089 Analog Comparator 7
1:1090 Analog Comparator 8
1:1091 Analog Comparator 9
1:1092 Analog Comparator 10
1:1093 Analog Comparator 11
1:1094 Analog Comparator 12
1:1095 Analog Comparator 13
1:1096 Analog Comparator 14
1:1097 Analog Comparator 15
1:1098 Logic Gate 1
1:1099 Logic Gate 2
1:1100 Logic Gate 3
1:1101 Logic Gate 4
1:1102 Logic Gate 5
1:1103 Logic Gate 6
1:1104 Logic Gate 7
1:1105 Logic Gate 8
1:1106 Logic Gate 9
1:1107 Logic Gate 10
1:1108 Logic Gate 11
1:1109 Logic Gate 12
1:1110 Logic Gate 13
1:1111 Logic Gate 14
1:1112 Logic Gate 15
1:1113 Logic Gate 16
1:1114 Logic Gate 17
1:1115 Logic Gate 18
1:1116 Logic Gate 19
1:1117 Logic Gate 20
1:1118 Logic Gate 21
1:1119 Logic Gate 22
1:1120 Logic Gate 23
1:1121 Logic Gate 24
1:1122 Logic Gate 25
1:1123 Logic Gate 26
1:1124 Logic Gate 27
1:1125 Logic Gate 28
ADDRESS DESCRIPTION
1:1126 Logic Gate 29
1:1127 Logic Gate 30
1:1128 Logic Gate 31
1:1129 Logic Gate 32
1:1130 Logic Gate 33
1:1131 Logic Gate 34
1:1132 Logic Gate 35
1:1133 Logic Gate 36
1:1134 Logic Gate 37
1:1135 Logic Gate 38
1:1136 Logic Gate 39
1:1137 Logic Gate 40
1:1138 Logic Gate 41
1:1139 Logic Gate 42
1:1140 Logic Gate 43
1:1141 Logic Gate 44
1:1142 Logic Gate 45
1:1143 Logic Gate 46
1:1144 Logic Gate 47
1:1145 Logic Gate 48
1:1146 Logic Gate 49
1:1147 Logic Gate 50
1:1148 Latch 1
1:1149 Latch 2
1:1150 Latch 3
1:1151 Latch 4
1:1152 Latch 5
1:1153 Latch 6
1:1154 Latch 7
1:1155 Latch 8
1:1156 Latch 9
1:1157 Latch 10
1:1158 Delay 1
1:1159 Delay 2
1:1160 Delay 3
1:1161 Delay 4
1:1162 Delay 5
1:1163 Delay 6
1:1164 Delay 7
1:1165 Delay 8
1:1166 Delay 9
1:1167 Delay 10
1:1168 Delay 11
1:1169 Delay 12
1:1170 Delay 13
1:1171 Delay 14
1:1172 Delay 15
1:1173 Delay 16
1:1174 Delay 17
1:1175 Delay 18
1:1176 Delay 19
1:1177 Delay 20
1:1178 Delay 21
1:1179 Delay 22
1:1180 Delay 23
