ProTechTPS Total Protection System Manual 26710V1
92 Woodward
Table 4-5 (continued). Boolean Read Addresses (Code 02)
ADDRESS DESCRIPTION
1:1181 Delay 24
1:1182 Delay 25
1:1183 Timer 1 HiHi
1:1184 Timer 1 Hi
1:1185 Timer 2 HiHi
1:1186 Timer 2 Hi
1:1187 Timer 3 HiHi
1:1188 Timer 3 Hi
1:1189 Timer 4 HiHi
1:1190 Timer 4 Hi
1:1191 Timer 5 HiHi
1:1192 Timer 5 Hi
1:1193 Unit Delay 1
1:1194 Unit Delay 2
1:1195 Unit Delay 3
1:1196 Unit Delay 4
1:1197 Unit Delay 5
1:1198 Unit Delay 6
1:1199 Unit Delay 7
1:1200 Unit Delay 8
1:1201 Unit Delay 9
1:1202 Unit Delay 10
1:1203 Reserved (Do not use)
1:1204 Reserved (Do not use)
1:1205 Reserved (Do not use)
1:1206 Internal Fault Trip Non-Latched
1:1207 Internal Fault Alarm Non-Latched
1:1208 Configuration Error
1:1209 Resettable Trip Input
1:1210 Power Supply 1 Fault
1:1211 Power Supply 2 Fault
1:1212 Parameter Error
1:1213 Reserved (Do Not Use)
1:1214 Analog Red Mgr 1 Input 1 Invalid
1:1215 Analog Red Mgr 1 Input 2 Invalid
1:1216 Analog Red Mgr 1 Input 3 Invalid
1:1217 Analog Red Mgr 2 Input 1 Invalid
1:1218 Analog Red Mgr 2 Input 2 Invalid
1:1219 Analog Red Mgr 2 Input 3 Invalid
1:1220 Analog Red Mgr 3 Input 1 Invalid
1:1221 Analog Red Mgr 3 Input 2 Invalid
1:1222 Analog Red Mgr 3 Input 3 Invalid
1:1223 Analog Red Mgr 4 Input 1 Invalid
1:1224 Analog Red Mgr 4 Input 2 Invalid
1:1225 Analog Red Mgr 4 Input 3 Invalid
1:1226 Analog Red Mgr 5 Input 1 Invalid
1:1227 Analog Red Mgr 5 Input 2 Invalid
1:1228 Analog Red Mgr 5 Input 3 Invalid
1:1229 Analog Red Mgr 6 Input 1 Invalid
1:1230 Analog Red Mgr 6 Input 2 Invalid
1:1231 Analog Red Mgr 6 Input 3 Invalid
1:1232 Analog Red Mgr 7 Input 1 Invalid
1:1233 Analog Red Mgr 7 Input 2 Invalid
1:1234 Analog Red Mgr 7 Input 3 Invalid
1:1235 Analog Red Mgr 8 Input 1 Invalid
ADDRESS DESCRIPTION
1:1236 Analog Red Mgr 8 Input 2 Invalid
1:1237 Analog Red Mgr 8 Input 3 Invalid
1:1238 Analog Red Mgr 9 Input 1 Invalid
1:1239 Analog Red Mgr 9 Input 2 Invalid
1:1240 Analog Red Mgr 9 Input 3 Invalid
1:1241 Analog Red Mgr 10 Input 1 Invalid
1:1242 Analog Red Mgr 10 Input 2 Invalid
1:1243 Analog Red Mgr 10 Input 3 Invalid
1:1244 Analog Red Mgr 11 Input 1 Invalid
1:1245 Analog Red Mgr 11 Input 2 Invalid
1:1246 Analog Red Mgr 11 Input 3 Invalid
1:1247 Analog Red Mgr 12 Input 1 Invalid
1:1248 Analog Red Mgr 12 Input 2 Invalid
1:1249 Analog Red Mgr 12 Input 3 Invalid
1:1250 Analog Red Mgr 13 Input 1 Invalid
1:1251 Analog Red Mgr 13 Input 2 Invalid
1:1252 Analog Red Mgr 13 Input 3 Invalid
1:1253 Analog Red Mgr 14 Input 1 Invalid
1:1254 Analog Red Mgr 14 Input 2 Invalid
1:1255 Analog Red Mgr 14 Input 3 Invalid
1:1256 Analog Red Mgr 15 Input 1 Invalid
1:1257 Analog Red Mgr 15 Input 2 Invalid
1:1258 Analog Red Mgr 15 Input 3 Invalid
1:1259 Bool Red Mgr Output 1
1:1260 Bool Red Mgr Output 2
1:1261 Bool Red Mgr Output 3
1:1262 Bool Red Mgr Output 4
1:1263 Bool Red Mgr Output 5
1:1264 Bool Red Mgr Output 6
1:1265 Bool Red Mgr Output 7
1:1266 Bool Red Mgr Output 8
1:1267 Bool Red Mgr Output 9
1:1268 Bool Red Mgr Output 10
1:1269 Bool Red Mgr Output 11
1:1270 Bool Red Mgr Output 12
1:1271 Bool Red Mgr Output 13
1:1272 Bool Red Mgr Output 14
1:1273 Bool Red Mgr Output 15
1:1274 Bool Red Mgr 1 Input 1 Invalid
1:1275 Bool Red Mgr 1 Input 2 Invalid
1:1276 Bool Red Mgr 1 Input 3 Invalid
1:1277 Bool Red Mgr 2 Input 1 Invalid
1:1278 Bool Red Mgr 2 Input 2 Invalid
1:1279 Bool Red Mgr 2 Input 3 Invalid
1:1280 Bool Red Mgr 3 Input 1 Invalid
1:1281 Bool Red Mgr 3 Input 2 Invalid
1:1282 Bool Red Mgr 3 Input 3 Invalid
1:1283 Bool Red Mgr 4 Input 1 Invalid
1:1284 Bool Red Mgr 4 Input 2 Invalid
1:1285 Bool Red Mgr 4 Input 3 Invalid
1:1286 Bool Red Mgr 5 Input 1 Invalid
1:1287 Bool Red Mgr 5 Input 2 Invalid
1:1288 Bool Red Mgr 5 Input 3 Invalid
1:1289 Bool Red Mgr 6 Input 1 Invalid
1:1290 Bool Red Mgr 6 Input 2 Invalid
