Table 4-5 (continued). Boolean Read Addresses (Code 02)
ADDRESS DESCRIPTION
1:1291 Bool Red Mgr 6 Input 3 Invalid
1:1292 Bool Red Mgr 7 Input 1 Invalid
1:1293 Bool Red Mgr 7 Input 2 Invalid
1:1294 Bool Red Mgr 7 Input 3 Invalid
1:1295 Bool Red Mgr 8 Input 1 Invalid
1:1296 Bool Red Mgr 8 Input 2 Invalid
1:1297 Bool Red Mgr 8 Input 3 Invalid
1:1298 Bool Red Mgr 9 Input 1 Invalid
1:1299 Bool Red Mgr 9 Input 2 Invalid
1:1300 Bool Red Mgr 9 Input 3 Invalid
1:1301 Bool Red Mgr 10 Input 1 Invalid
1:1302 Bool Red Mgr 10 Input 2 Invalid
1:1303 Bool Red Mgr 10 Input 3 Invalid
1:1304 Bool Red Mgr 11 Input 1 Invalid
1:1305 Bool Red Mgr 11 Input 2 Invalid
1:1306 Bool Red Mgr 11 Input 3 Invalid
1:1307 Bool Red Mgr 12 Input 1 Invalid
1:1308 Bool Red Mgr 12 Input 2 Invalid
1:1309 Bool Red Mgr 12 Input 3 Invalid
1:1310 Bool Red Mgr 13 Input 1 Invalid
1:1311 Bool Red Mgr 13 Input 2 Invalid
1:1312 Bool Red Mgr 13 Input 3 Invalid
1:1313 Bool Red Mgr 14 Input 1 Invalid
1:1314 Bool Red Mgr 14 Input 2 Invalid
1:1315 Bool Red Mgr 14 Input 3 Invalid
1:1316 Bool Red Mgr 15 Input 1 Invalid
1:1317 Bool Red Mgr 15 Input 2 Invalid
1:1318 Bool Red Mgr 15 Input 3 Invalid
1:1319 Difference Detection 1
1:1320 Difference Detection 2
1:1321 Difference Detection 3
1:1322 Difference Detection 4
1:1323 Difference Detection 5
1:1324 Difference Detection 6
1:1325 Difference Detection 7
1:1326 Difference Detection 8
1:1327 Difference Detection 9
1:1328 Difference Detection 10
1:1329 Difference Detection 11
1:1330 Difference Detection 12
1:1331 Difference Detection 13
1:1332 Difference Detection 14
1:1333 Difference Detection 15
1:1334 Speed Red Mgr Input 1 Invalid
1:1335 Speed Red Mgr Input 2 Invalid
1:1336 Speed Red Mgr Input 3 Invalid
1:1337 Speed Red Mgr Input Difference
1:1338 Accel Red Mgr Input 1 Invalid
1:1339 Accel Red Mgr Input 2 Invalid
1:1340 Accel Red Mgr Input 3 Invalid
1:1341 Speed Probe Open Wire Alarm Non-Latched
1:1342 Speed Red Mgr Trip Non-Latched
1:1343 Reserved (Do Not Use)
1:1344 Reserved (Do Not Use)
1:1345 Reserved (Do Not Use)
ADDRESS DESCRIPTION
1:1401 Module A Discrete Input 1
1:1402 Module A Discrete Input 2
1:1403 Module A Discrete Input 3
1:1404 Module A Discrete Input 4
1:1405 Module A Discrete Input 5
1:1406 Module A Discrete Input 6
1:1407 Module A Discrete Input 7
1:1408 Module A Discrete Input 8
1:1409 Module A Discrete Input 9
1:1410 Module A Discrete Input 10
1:1411 Module B Discrete Input 1
1:1412 Module B Discrete Input 2
1:1413 Module B Discrete Input 3
1:1414 Module B Discrete Input 4
1:1415 Module B Discrete Input 5
1:1416 Module B Discrete Input 6
1:1417 Module B Discrete Input 7
1:1418 Module B Discrete Input 8
1:1419 Module B Discrete Input 9
1:1420 Module B Discrete Input 10
1:1421 Module C Discrete Input 1
1:1422 Module C Discrete Input 2
1:1423 Module C Discrete Input 3
1:1424 Module C Discrete Input 4
1:1425 Module C Discrete Input 5
1:1426 Module C Discrete Input 6
1:1427 Module C Discrete Input 7
1:1428 Module C Discrete Input 8
1:1429 Module C Discrete Input 9
1:1430 Module C Discrete Input 10
1:1431 Module A Trip Latch Out
1:1432 Module A Alarm Latch Out
1:1433 Module B Trip Latch Out
1:1434 Module B Alarm Latch Out
1:1435 Module C Trip Latch Out
1:1436 Module C Alarm Latch Out
1:1501 Heartbeat
