Table 4-6. Analog Read Addresses (Code 04)
Note:
The Last Trip time and date indication registers (3:1001 - 1007) are provided for
use as a way to time-stamp when a trip condition occurs. With this logic, when a
trip condition occurs the first sensed trip condition will be indicated by one of the
registers (1:0101 - 0137) changing to a true state. When one of those registers
change to a true state, then the Last Trip time and date indication registers
(3:1001 - 1007) will indicate the sensed date and time of the event. This
Date/Time will remain in locked in these registers until the next trip condition
occurs.
ADDRESS DESCRIPTION UNITS RANGE
3:0001 Speed (after Speed Red Mgr, if used) RPM 0 to 32500
3:0002 Acceleration (after Accel Red Mgr, if used) RPM/s -32500 to 32500
3:0003 Module A Speed RPM 0 to 32500
3:0004 Module A Acceleration RPM/s -32500 to 32500
3:0005 Module B Speed RPM 0 to 32500
3:0006 Module B Acceleration RPM/s -32500 to 32500
3:0007 Module C Speed RPM 0 to 32500
3:0008 Module C Acceleration RPM/s -32500 to 32500
3:0009 Overspeed Setpoint (Local) RPM 0 to 32500
3:0101 to 0110 Analog Inputs (Local) 1 to 10 User Units -32768 to 32767
3:0201 to 0210 Module A Analog Inputs 1 to 10 User Units -32768 to 32767
3:0301 to 0310 Module B Analog Inputs 1 to 10 User Units -32768 to 32767
3:0401 to 0410 Module C Analog Inputs 1 to 10 User Units -32768 to 32767
3:0501 Trip Cycle Time 1 ms 0 to 65535
3:0502 Trip Cycle Time 2 ms 0 to 65535
3:0601 Test Mode Time Remaining s 0 to 65535
3:0701 Speed Fail Time Remaining s 0 to 65535
3:0801 Timer 1 Seconds s 0 to 65535
3:0802 Timer 1 Milliseconds ms 0 to 999
3:0803 Timer 2 Seconds s 0 to 65535
3:0804 Timer 2 Milliseconds ms 0 to 999
3:0805 Timer 3 Seconds s 0 to 65535
3:0806 Timer 3 Milliseconds ms 0 to 999
3:0807 Timer 4 Seconds s 0 to 65535
3:0808 Timer 4 Milliseconds ms 0 to 999
3:0809 Timer 5 Seconds s 0 to 65535
3:0810 Timer 5 Milliseconds ms 0 to 999
3:0901 Temp Overspeed Setpoint RPM 0 to 65535
3:0902 Simulated Speed RPM RPM 0 to 65535
3:1001 Last Trip Month Months 1 to 12
3:1002 Last Trip Day Days 1 to 31
3:1003 Last Trip Year Years 2000 to 2099
3:1004 Last Trip Hour Hours 0 to 23
3:1005 Last Trip Minute Minutes 0 to 59
3:1006 Last Trip Second Sec 0 to 59
3:1007 Last Trip Millisecond ms 0 to 999
3:1101 Unit Health Status Enum 0 to 2
3:1201 Auto-Sequence Test Status Enum 0 to 3
