Worcester 25/32 - Short Parts List 25;32

S
H
ORT PARTS LIST 25/32
I
N
S
TALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY KITCHEN 12/18-18/25-25/32
8 716 113 000a (01/07)
46
SERVICING
& SPARES
SHORT PARTS LIST 25/32
1 Burner - Riello R
DB 2.2 25/32 HE
Part Number: 8-7
16-112-347-0
2 Combustion head - T2 LH25/32
Part Number: 8-716-112-769-0
3 Control box 535 RSE/LD
Part Number: 8-716-109-203-0
4 Photocell
Part Number: 8-716-109-193-0
5 Ignition electrode
Part Number: 8-716-109-183-0
6 Motor
Part Number: 8-716-109-186-0
7 Oil pump - Riello RDB
Part Number: 8-716-109-182-0
7a Pump coupling
Part Number: 8-716-109-245-0
8 Flexible oil line kit
Part Number: 8-716-106-346-0
9 Burner 'O' ring
Part Number: 8-7
16-109-328-0
10 Control thermostat
Part Number: 8-7
16-107-621-0
1
1 Auto reset overheat thermostat
Part Number: 8-716-107-640-0
1
2 Manual reset overheat thermostat
Part Number: 8-716-107-625-0
13 Manual reset flue thermostat
Part Number: 8716-107-624-0
14 Cleaning brush
Part Number: 8-716-109-428-0
15 Manifold access cover seal
Part Number: 8-716-107-536-0
16 Secondary Heat Exchanger gasket
Part Number: 8-716-112-954-0
78
11
15 16
13
12
14
2
3456
9
10
1
7a
