6 720 610 576 GB (03.02)
Appendix
45
9.3 Heating/hot water output settings
ZWB 7-25 N.G.
9.4 Heating/hot water output settings
ZWB 11-25 L.P.G.
9.5 Heating/hot water output settings
ZWB 7-30 N.G.
9.6 Heating/hot water output settings
ZWB 11-30 L.P.G.
Natural gas G20
Display
code
Heat output
kW
Heat
input kW
Gas vol. flow
rate (l/min at
t
V
/t
R
= 80/60˚C)
30 8.2 8.3 14.4
40 10.9 11.0 19.3
50 13.6 13.8 24.1
60 16.3 16.5 28.9
70 19.1 19.3 33.7
80 21.8 22.0 38.5
90 24.5 24.8 43.3
100 27.2 27.5 48.1
Table 20
Propane
Display
code
Heat output kW Heat input kW
40 10.9 11.0
50 13.6 13.8
60 16.3 16.5
70 19.1 19.3
80 21.8 22.0
90 24.5 24.8
100 27.2 27.5
Table 21
Natural gas G20
Display
code
Heat output
kW
Heat
input kW
Gas vol. flow
rate (l/min at t
V
/
t
R
=
80/60˚C)
30 8.8 8.9 15.5
40 11.7 11.8 20.7
50 14.6 14.8 25.8
60 17.5 17.7 31.0
70 20.4 20.7 36.1
80 23.4 23.6 41.3
90 26.3 26.6 46.5
100 29.2 29.5 51.6
Table 22
Propane
Display
code
Heat output kW Heat input kW
40 11.7 11.8
50 14.6 14.8
60 17.5 17.7
70 20.4 20.7
80 23.4 23.6
90 26.3 26.6
100 29.2 29.5
Table 23
