Electrical connections
23
B Cut cable grommet to diameter of cable.
Fig. 27
B Feed cable through cable grommet and connect the
mains supply cable, see fig. 28.
B Secure cable in cable grommet by means of cable
grip.
Fig. 28
4.2 Connecting TR2 Room thermostat
The TR2 should be connected to terminals 3, 4 and F
beneath the Textdisplay, page 8, fig. 4, item 422.
4.3 Mains Voltage external controls
connections
Fig. 29
Note: If an external timer is used then the domestic hot
water pre-heat facility can only be isolated by actuating
the ECO-button.
