I/O specifications
Metering (analog inputs)
12-bit -60 V/+60 V (4 ranges)
Status (digital inputs)
5-25 VDC external or contact closure
Commands (relay outputs)
1 A @ 50 VDC per relay - SPDT
2.3. Network configuration
! This unit does not deal with network related security issues. It is up to the user to set it in a secured
environment such as a private network, VPN, behind a firewall…
To successfully communicate with clients and various services, the Audemat Control Silver uses the following
ports:
Port 21
FTP - file transfer
Port 22
SSH - maintenance
Port 80
HTTP - communication with the client PC
Port 161
SNMP - SNMP commands (to read variables)
Port 443
HTTPS - secured web communication
Port 5570
ScriptEasy - visualization of the script in real time
Port 25
SMTP - sending of emails
Port 123
NTP - date/time synchronization
Port 162
SNMP - sending of traps and reception of acknowledgment
You may need to open these ports on the firewall for the Audemat Control Silver to work properly. Ask your
network administrator if necessary.
