Materials List
2 Freedom XC Owner's Guide
Materials List
The Freedom XC base package includes the following items:
n one Freedom XC unit
n one Owner’s Guide and extra safety labels
n one pre-installed DC ground enclosure lug (not shown)
n one set of plastic bushings for large DC cables
a
(not shown)
Figure 1 What’s In The Box
NOTE: If any of the items are missing, contact Xantrex or any
authorized Xantrex dealer for replacement. See Contact
Information on page ii.
a
Available only to the Freedom XC 2000 only.
Key Features
Power for Most
Appliances
The Freedom XCinverter/charger provides up
to 1000 watts (Freedom XC 1000) or
2000watts
2
(Freedom XC 2000) of
continuous utility grade, sine wave power
derived from a battery bank. It is designed to
handle loads such as microwave ovens, TVs,
DVD/Blu-ray players, and power tools. In
addition, the Freedom XC’s high-surge
capability lets you handle many hard-to-start
loads, including full size residential
refrigerators.
The built-in transfer switch automatically
transfers between inverter power and shore
power from recreational facilities such as boat
docks or campsites to ensure power is
always available.
2
As the temperature on the Freedom XC rises, it will gradually reduce its continuous power output from
2000W at 40°C ambient to 1500W before the over-temperature shutdown occurs at 60°C ambient. See
Specifications on page 83.

Xantrex Freedom XC 2000 Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Frequency	60 Hz
Waveform	Pure Sine Wave
Efficiency	90%
Operating Temperature	-4°F to 140°F (-20°C to 60°C)
Transfer Time	20ms
