Viewing Information During Battery Mode
975-0784-01-01 47
Viewing Information During
Battery Mode
The LCD screen displays information related to battery mode
operation.
l
Press the Scroll button to move from screen to screen.
Press and hold for three seconds to go back one step.
Info and Setting LCD Screen
Screen 1 of 4 -
Battery
Voltage/Load
Wattage
This is the home
screen.
battery voltage = 12.5V, AC load =
1.2kW
Info and Setting LCD Screen
Screen 2 of 4 -
AC Output
Voltage/Frequency
output voltage = 120V, output frequency=
60Hz
Screen 3 of 4 -
AC Input
Voltage/Frequency
Screen shows up
when utility AC is
connected.
input voltage = 120V, input frequency =
60Hz

Xantrex Freedom XC 2000 Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Frequency	60 Hz
Waveform	Pure Sine Wave
Efficiency	90%
Operating Temperature	-4°F to 140°F (-20°C to 60°C)
Transfer Time	20ms
