Xantrex Freedom XC 2000 User Manual

Regulatory Approvals
90 Freedom XC Owner's Guide
Regulatory Approvals
Freedom XC 1000 Freedom XC 2000
Safety
ETL-listed complies to CSA 107.1
UL458 and UL458 Marine Supplement (drip
shield with product number 808-1050
required)
ABYC E-11, A-31, A-32
ETL-listed complies to CSA 107.1
UL458 and UL458 Marine Supplement (drip
shield with product number 808-1050
required)
ABYC E-11, A-31, A-32
EMC
CFR47, (FCCPart15) Subpart B, ClassB
CAN ICES-3(B)/NMB-3(B)
CFR47, (FCCPart15) Subpart B, ClassB
CAN ICES-3(B)/NMB-3(B)
Table 24Regulatory approvals

Xantrex Freedom XC 2000 Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Frequency	60 Hz
Waveform	Pure Sine Wave
Efficiency	90%
Operating Temperature	-4°F to 140°F (-20°C to 60°C)
Transfer Time	20ms
