Operating in Grid Mode
66 Freedom XC Owner's Guide
Power Output
The Freedom XC can deliver up to 1000 watts (Freedom XC 1000)
or 2000watts
3
(Freedom XC 2000) of continuous utility grade sine
wave AC power. The wattage rating applies to resistive loads
such as incandescent lights.
3
As the temperature on the Freedom XC 2000 rises, it will gradually reduce its continuous power output
from 2000 W at 40°C ambient to 1500 W before the over-temperature shutdown occurs at 60°C ambient.
See Specifications on page 83.
Input Voltage
The allowable Freedom XC input battery voltage ranges are
shown in the following table:
Operating
Condition
Battery
Voltage
Comment
Full
Operating
Range
LBCO –
18.0 volts
Assuming the battery is full, the
inverter/charger will operate until
battery voltage goes past below
LBCO
d
and LBCO Shutdown
delay timer
e
.
Low
Voltage
Recovery
<LBCO+0.2
volts
Inverter is able to recover and
continue to operate.
Table 13Input battery voltage range
d
To set LBCO, see Adjusting Settings in Configuration Mode on page 51.
e
To set LBCO Shutdown Delay Timer, see Input Voltage on page 66.

Xantrex Freedom XC 2000 Specifications

General

Continuous Power	2000W
Surge Power	4000W
Input Voltage	12V DC
Output Voltage	120V AC
Output Frequency	60 Hz
Waveform	Pure Sine Wave
Efficiency	90%
Operating Temperature	-4°F to 140°F (-20°C to 60°C)
Transfer Time	20ms
