Advanced Setup Summary
976-0043-01-02 7–5
Table 7-2
Advanced Setup Default Settings for the Sine Wave Plus 4024 and 4048 Models
Advanced Setup Menus
Sine Wave Plus 4024 Sine Wave Plus 4048
See PageRange/Display
Default
Settings Range/Display
Default
Settings
20 Silent Setup Menu See “20 Silent Setup Menu” on page 7–13 for details.
20A Refloat High Volts DC 16.1 to 33.9 28.4 32.2 to 67.8 56.8 page 7–15
20B Refloat Low Volts DC 16.1 to 33.8 25.0 32.2 to 67.8 50.0 page 7–15
20C Float Done Amps AC 00 to 40 10 00 to 40 10 page 7–15
20D Must Float Time Min 00 to 255 05 00 to 255 05 page 7–15
End Menu 20
21 Grid AC1 Usage Menu See “21 Grid (AC1) Usage Menu” on page 7–16 for details.
21A Grid Usage SB BX SB SB BX SB page 7–17
21B Grid Usage Begin h:m 00:00 to 23:50 21:00 00:00 to 23:50 21:00 page 7–17
21C Grid Usage End h:m 00:00 to 23:50 21:00 00:00 to 23:50 21:00 page 7–18
End Menu 21
22 Battery Xfer (BX) Menu See “22 Battery Xfer (BX) Menu” on page 7–18 for details.
22A High Xfer (HBX) Vdc 16.1 to 33.9 27.0 32.2 to 67.8 54.0 page 7–19
22B Low Xfer (LBX) Vdc 16.1 to 33.8 23.0 32.2 to 67.8 46.0 page 7–19
End Menu 22
23 ALM Relays Menu See “23 ALM Relays Menu” on page 7–19 for details.
23A RY9 VDC Energized 22.1 to 35.5 26.0 44.2 to 71.0 52.0 page 7–20
23B RY9 VDC DeEnergized 20.0 to 35.5 22.0 40.0 to 71.0 44.0 page 7–20
23C RY9 Delay at DeEngz.
Min
00 to 255 10 00 to 255 10 page 7–20
23D RY10 VDC Energized 10.0 to 32.0 28.8 20.0 to 64.0 57.6 Vdc page 7–20
23E RY10 VDC DeEnergized 10.0 to 32.0 26.8 20.0 to 64.0 53.6 Vdc page 7–21
23F RY10 Delay at DeEngz.
Min
00 to 255 10 00 to 255 10 page 7–21
23G RY11 Mode Cooldown Error Error Cooldown Error Error page 7–21
End Menu 23
24 Generator Timers Menu See “24 Generator Timers Menu” on page 7–26 for details.
24A Gen Run Time Start h:m 00:00 to 23:50 08:00 00:00 to 23:50 08:00 page 7–27
