Basic Features
976-0043-01-02 1–3
Front Panel
The front of the Sine Wave Plus has the following features:
• the Inverter Control Module (ICM) Display
• the AC Access Cover
Figure 1-1
The Sine Wave Plus
Figure 1-2
The Front Side of the Sine Wave Plus
AC Access Cover
Inverter Control Module Display
