Xantrex SW Plus 2524

Pre-Installation
976-0043-01-02 3–11
Figure 3-4 Wall-Mounting Method using 2 x 4’s
Wall studs 16 inches
on center
Wallboard
Floor
Ceiling
14–3/8"
c-c
Set Inv erter
OFF SRCH ON CHG
Sine Wave Plus
Inverter/Charger
Approx.
4–5 ft
2 x 4
mounti ng
supports
Mounting
Holes (10)
Keyhole Slots
(4)
