Pre-Installation
976-0043-01-02 3–3
Hardware / Materials Required
The following materials may be required for completing this installation.
❐ 4' x 8' sheet of ¾" plywood for mounting
❐ 2 x 4 boards for mounting
❐ #10 and/or #12 wood screws (or ½" x 1¼" lag bolts)
❐ Conduits and appropriate fittings for wire runs (e.g., wire nuts)
❐ Electrical wire of appropriate size and length
❐ Battery cable lugs (depending on types of battery cables used)
❐ Breaker panels
❐ Ground busses, bars, bonding blocks, and/or rods
Optional System Accessories
The following optional system accessories can be used in the installation
of the Sine Wave Plus. These accessories are available from any
authorized Xantrex dealer. Consult with your local system designer to
determine what optional equipment will be needed for your specific
installation.
Conduit boxes:
❐ ACCB with input/output/bypass breakers
❐ DCCB
Battery cables:
❐ BC1.5 (Single) Battery Interconnects
❐ BC2/0 AWG (Pair), available in 5 and 10 foot lengths
❐ BC4/0 AWG (Pair), available in 5, 10, and 15 foot lengths
DC disconnects and fuses:
❐ DC175 (175 Amp DC Disconnect with Bonding Bar)
❐ DC250 (250 Amp DC Disconnect with Bonding Bar)
❐ TFB 200 (200 Amp Class-T Fuse)
❐ TFB 300 (300 Amp Class-T Fuse)
❐ TFB 400 (400 Amp Class-T Fuse)
❐ PV Ground Fault Projection (PVGFP1, PVGFP2, PVGFP3,
PVGFP4)
