Xantrex SW Plus 2524 User Manual

Installation
3–20 976-0043-01-02
Connecting the Batteries to the Inverter
DC terminal connections are located on the DC end of the inverter.
Figure 3-10 shows the locations of the DC connectors.
WARNING: Shock Hazard
Before making any connections, verify that the DC disconnect device is
switched OFF.
Figure 3-10 DC Terminal Connections on the Inverter
DC End of the Inverter
Positive (+) Red
DC Terminal
Negative (–) Black
DC Terminal
