Xantrex SW Plus 2524 User Manual

Operation
8–10 976-0043-01-02
ERROR LED
(red)
No error has been
detected.
An Inverter error condition has
been detected.
Use 05 Error Causes Menu to
determine the cause of the error.
This error LED will be on if
either an inverter and/or a
generator error condition has
been detected.
A generator error has been
detected.
Use 05 Error Causes Menu to
determine the cause of the
Error.
If the Error LED flashes and no
Error cause is displayed in
05 Error Causes, then the AC
input frequency is in need of
adjustment.
STATUS
LED
(yellow)
No Status condition
has been detected.
A Status condition has been
detected as described in
“STATUS LED (Yellow)” on
page 8–8.
Use 06 Status Menu to
determine your particular status
condition.
A Status condition has been
detected and a pending error
condition may occur if this
status condition continues.
Use 06 Status Menu to
determine your particular status
condition.
Table 8-1 LED Summary Table
LED Name OFF ON FLASHING
