The User Menu Summary
976-0043-01-02 8–13
05F External err (stacked)
NO YES Read Only NO YES Read Only page 8–27
05G Input Relay Failure
NO YES Read Only NO YES Read Only page 8–27
05H Gen Failed to Start
NO YES Read Only NO YES Read Only page 8–28
05I Gen Stopped due to V/F
NO YES Read Only NO YES Read Only page 8–28
End Menu 05
06 Status Menu See “06 Status Menu” on page 8–28 for details.
06A Bypass Mode Selected
NO YES Read Only NO YES Read Only page 8–29
06B CHR Selected (no backup)
NO YES Read Only NO YES Read Only page 8–29
06C Gen Signalled to Run
NO YES Read Only NO YES Read Only page 8–29
06D Gen in Cooldown
NO YES Read Only NO YES Read Only page 8–29
06E EQ Charge Selected
NO YES Read Only NO YES Read Only page 8–30
06F Battery Vdc < LBCO
NO YES Read Only NO YES Read Only page 8–30
06G Battery Vdc > HBCO
NO YES Read Only NO YES Read Only page 8–30
06H EPO shutdown
NO YES Read Only NO YES Read Only page 8–30
End Menu 06
07 GSM/ALM Menu See “07 GSM/ALM Options Menu” on page 8–30 for details.
07A RY7 (GSM) Energized
NO YES Read Only NO YES Read Only page 8–30
07B RY8 (GSM) Energized
NO YES Read Only NO YES Read Only page 8–31
07C RY9 (ALM) Energized
NO YES Read Only NO YES Read Only page 8–31
07D RY9 DeEngz. Time Minute
00 to 255 Read Only 00 to 255 Read Only page 8–31
07E RY10 (ALM) Energized
NO YES Read Only NO YES Read Only page 8–31
07F RY10 Engz. Time Minute
00 to 255 Read Only 00 to 255 Read Only page 8–31
07G RY11 Energized
NO YES Read Only NO YES Read Only page 8–31
End Menu 07
END USER MENU
Table 8-2 User Menu
User Menus
Sine Wave Plus
2524 and 4024
Sine Wave Plus
2548,4048, and 5548
See Page
Range/
Display
Default
Settings
Range/
Display
Default
Settings
