Xantrex SW Plus 2524 User Manual

Mechanical Specifications
976-0043-01-02 A–5
Mechanical
Specifications Sine Wave Plus 4024 Sine Wave Plus 4048 Sin e Wave Pl us 55 48
Operating
Temperature Range
SPECIFIED
(will meet specified
tolerances)
32 °F to 77 °F
(0 °C to 25 °C)
32 °F to 77 °F
(0 °C to 25 °C)
32 °F to 77 °F
(0 °C to 25 °C)
ALLOWED
(may not meet
specified tolerances)
-13 °F to 140 °F
(-25 °C to 60 °C)
-13 °F to 140 °F
(-25 °C to 60 °C)
-13 °F to 140 °F
(-25 °C to 60 °C)
NON-OPERATING
(storage)
-67 °F to 284 °F
(-55 °C to 140 °C)
-67 °F to 284 °F
(-55 °C to 140 °C)
-67 °F to 284 °F
(-55 °C to 140 °C)
Enclosure Type Indoor, ventilated,
Galvaneel steel chassis
with powder coat finish
Indoor, ventilated,
Galvaneel steel chassis
with powder coat finish
Indoor, ventilated,
Galvaneel steel chassis
with powder coat finish
Unit Weight 117 lb (53 kg) 117 lb (53 kg) 136 lb (62 kg)
Shipping Weight 126 lb (57 kg) 126 lb (57 kg) 145 lb (66 kg)
Inverter Dimensions
(H x W x D)
15 1/8" x 21" x 8 7/8"
(38 cm x 53 cm x 22 cm)
15 1/8" x 21" x 8 7/8"
(38 cm x 53 cm x 22 cm)
15 1/8" x 21" x 8 7/8"
(38 cm x 53 cm x 22 cm)
Shipping Dimensions
(H x W x D)
20" x 27 7/8" x 14 1/4"
(51 cm x 71 cm x 36 cm)
20" x 27 7/8" x 14 1/4"
(51 cm x 71 cm x 36 cm)
20" x 27 7/8" x 14 1/4"
(51 cm x 71 cm x 36 cm)
Mounting Wall or Shelf Mount Wall or Shelf Mount Wall or Shelf Mount
See Certification Label for specific regulatory agency approval information.

Xantrex SW Plus 2524 Specifications

General

Brand	Xantrex
Model	SW Plus 2524
Category	Inverter
Language	English
