1. Load your original documents.
• For single pages or paper that cannot be fed using the duplex automatic document feeder, use the
document glass. Lift the duplex automatic document feeder, then place the original document face down in
the upper-left corner of the document glass.
• For multiple, single, or 2-sided pages, use the duplex automatic document feeder. Remove any staples and
paper clips from the pages. Insert the original documents face up in the duplex automatic document
feeder, with the top of the page entering the feeder first. Adjust the paper guides so that they fit against
the original documents.
Note: When the original documents are detected, the automatic document feeder confirmation indicator
LED illuminates.
2. At the printer control panel, press the HHoommee button.
3. Touch WWoorrkkffllooww SSccaannnniinngg.
4. To clear previous app settings, touch RReesseett.
5. To select a workflow, from the Pick a Workflow screen, touch an option. If necessary, to refresh the workflow list,
touch UUppddaattee.
Note: If the Pick a Workflow screen does not appear automatically, to display the screen, touch CChhaannggee
WWoorrkkffllooww.
Xerox
®
AltaLink
®
C8130/C8135/C8145/C8155/C8170 Series Color Multifunction Printer User Guide 125
Xerox® Apps

Xerox AltaLink C8130 Series Specifications

General

Maximum Paper Capacity	5, 140 sheets
Copy Resolution	Up to 600 x 600 dpi
Fax	Optional
Scan Resolution	Up to 600 x 600 dpi
Duplex Printing	Automatic
Memory	4 GB
Type	Color Multifunction Printer
Fax Resolution	Up to 400 x 400 dpi
Display	10.1-inch color touchscreen
Print Speed	Up to 30 ppm
Connectivity	Ethernet, USB 3.0
Hard Drive	320 GB (optional)
Functions	Print, Copy, Scan, Fax (optional)
Copy Speed	Up to 30 cpm (black/white and color)
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria, Xerox Print Service Plug-in for Android
Dimensions	640 x 699 x 1, 147 mm
Print Resolution	Up to 1200 x 2400 dpi
